RZ-MR

Drawing

General

Product Code:

RZ-MR

Luminaire Type:

Spot light

Body Construction:

Aluminum

Surface Finishes:

Texture Black / Any RAL color possible on request

IP Rating:

20

Physical

Dimension Ø x H:

45mm x 100mm (with Hood)

Fixing System:

Fixed with allen key screw

LED

Light Source:

LED

CCT:

3000K / 4000K / 5000K

CRI:

80+, 90+, Available on request

MacAdam Step:

3

Optical

Light Distribution:

Direct

Beam Angle:

24* , 40* , 60*

Electrical

System Wattage:

5W, 8.5W, 10.7W, 13W

Power Factor:

0.94

Driver

Non-Dimmable

DALI Dimmable

0-10V Analogue Dimmable

Phase Cut Dimmable

Bluetooth 4.0 CASAMBI remote control through App

Downloads

RZ-MR Data Sheet

RZ-MR Custom Data Sheet

RZ-MR Installation Manual

RZ-MR IES files

Download All Except custom data sheet

Disclaimer: *Images are for display purposes only and could be different based on the type chosen. For better understanding, please refer to the diagrams.
